4 Wheel Electric Forklift Truck Pneumatic Tyre
Power, increased battery life and performance for demanding applications
- Models
- FB15-35RZ 2
- Capacity
- 1500-3500kg
The FB15-35RZ 2 counterbalanced lift truck combines the power, clean performance and battery life modern operations require, all with advanced technology to keep business running smoothly, shift after shift.
- Powerful performance
- Ergonomic advantages
Modern electric lift truck designed to meet the demands of today's operations
Powerful performance
Ergonomic advantages
The FB-RZ counterbalanced lift truck series is packed with electric power and productivity enhancing features your operation needs to meet ambitious performance targets.
- AC controlled traction and hoist / steer motors provide rigorous performance to meet material handling needs
- Regenerative braking charges battery during brake cycles to extend battery life
- Adjustable performance modes to deliver right mix of energy efficiency and productivity to optimize operating cost
- Battery life extends from up to 8.5 hours to up to 9.5 hours in Eco mode
- Automatic speed reduction based on load and steering angle
In high-throughput logistics operations, lift truck operators must perform at their peak, all shift long. The FB-RZ series delivers ergonomic advantages to help maximize labor efficiency.
- Operator compartment offers easy access, cushioned seat and space for operator comfort
- Asynchronous and power assist steering ensures alignment between rotation of steering wheel and tires, enabling wheel to always return to same center position
- Operator presence system will disengage truck function if operator leaves seat
- Wide inner mast clearance optimizes mast visiblity for greater operator efficiency
- Carriage light eminates from just above forks to illuminate workspace when operating at height
- Blue pedestrian awareness light provides an additional alert to pedestrian and mobile equipment operators that forklifts are nearby
| Model | Load Capacity | Load Centre | Lift Height | Turning Radius | Battery Capacity |
|---|---|---|---|---|---|
| FB18RZ 2 | 1800kg | 500mm | 6025mm | 1875mm | 48V / 390-525Ah(V/Ah) |
| FB20RZ 2 | 2000kg | 500mm | 6035mm | 1990mm | 48V / 440-700Ah(V/Ah) |
| FB20SRZ 2 | 2000kg | 500mm | 6030mm | 1910mm | 48V / 390-525Ah(V/Ah) |
| FB25RZ 2 | 2500kg | 500mm | 6035mm | 2035mm | 48V / 565-700Ah(V/Ah) |
| FB30RZ 2 | 3000kg | 500mm | 6025mm | 2190mm | 48V / 440-600Ah(V/Ah) |
| FB35SRZ 2 | 3500kg | 500mm | 6030mm | 2255mm | 48V / 440-600Ah(V/Ah) |
