Platform Low Lift Pallet Truck
Designed around the needs of the operator
- Models
- MP20-30X
- Capacity
- 2000-3000kg
Provides performance enhancing options and standard features that increase productivity and reduces operational costs.
- Increased productivity
- Ergonomic tiller head and controls
- Large operator platform
- Exceptional manoeuvrability
- Maintenance free
Provides performance enhancing options and standard features that increase productivity and reduces operational costs.
Increased productivity
Ergonomic tiller head and controls
Large operator platform
Exceptional manoeuvrability
Maintenance free
Impressive traction speed up to 13km/h unladen and 9.7km/h laden on the 2.0T and 2.5T trucks, combined with progressive speed reduction, allows operators to move loads quickly and efficiently.
The tiller head has an ergonomic shaped handle with integral hand guard and spring assisted to return automatically to the vertical position. Whilst the large, low-effort butterfly buttons control travel direction, speed and the electromagnetic brake.
The large operator platform allows the operator to find their own comfortable driving position and has an “operator on board” sensor, preventing truck operation when no driver is present
Minimum effort is required to manoeuvre the truck, so the operator can work with less effort and arm movement, reducing fatigue and increasing productivity. The 750mm width allows the handling of loads in tight spaces, such as inside containers or on lorry trailers.
The maintenance-free motor (inspection intervals required every 1000 operating hours) provides low-cost long operating life.
| Model | Load Capacity | Lift Height | AST (wide / long) | Battery Capacity | Weight |
|---|---|---|---|---|---|
| MP20X | 2000kg | 120mm | 2421 / 2335mm | 24V / 210 - 500Ah(V/Ah) | 678kg |
| MP20X platform with rear protection | 2000kg | 120mm | 2998 / 2912mm | 24V / 210 - 500Ah(V/Ah) | 807kg |
| MP20X platform with side protection | 2000kg | 120mm | 2902 / 2816mm | 24V / 210 - 500Ah(V/Ah) | 823kg |
| MP25X platform with rear protection | 2500kg | 120mm | 2998 / 2912mm | 24V / 315-500Ah(V/Ah) | 824kg |
| MP25X | 2500kg | 120mm | 2492 / 2406mm | 24V / 315-500Ah(V/Ah) | 785kg |
| MP25X platform with side protection | 2500kg | 120mm | 2902 / 2816mm | 24V / 315-500Ah(V/Ah) | 840kg |
| M30X platform with side protection | 3000kg | 120mm | 2902 / 2816mm | 24V / 315-500Ah(V/Ah) | 840kg |
| M30X | 3000kg | 120mm | 2492 / 2406mm | 24V / 315-500Ah(V/Ah) | 785kg |
| M30X platform with rear protection | 3000kg | 120mm | 2998 / 2912mm | 24V / 315-500Ah(V/Ah) | 824kg |
